Product Description:
The Rohde & Schwarz FSWP26 phase noise analyzer and VCO tester is the best test solution for radar applications and for the development and manufacture of synthesizers, OCXO, DRO and VCO. It can be easily configured to suit the desired application. The instrument's low-noise internal local oscillator can measure most commercially available synthesizers and oscillators without any additional options.
For high-end applications, the Rohder & Schwarz FSWP26 can be equipped with a second receiving path that enables cross-correlation and increases sensitivity by up to 25 dB depending on the quantity of correlation used. The analyzer has excellent internal sources and most of the digital architecture, making it faster than test systems that digitize the signal after the phase detector. The FSWP26 not only measures phase noise, it is also a full-featured signal and spectrum analyzer.
Product Features:
The frequency range is 1 MHz to 26.5 GHz
Both amplitude and phase noise are measured
Internal sources used to measure residual phase noise, including pulse signals
Automatic VCO characterization
The frequency offset is up to 300 MHz for phase noise measurements and up to 1 GHz for pure noise measurements
