Product Description:
The N9000A (Agilent) CXA Signal Analyzer is a versatile, low-cost tool for basic signal characterization. It can help you accelerate product testing and development on multiple levels; Reduce costs, increase production, enhance design, and more. Get the basics with the X-Series extensibility in CXA - and expect more.
We can't predict the future, but we can help you shape it with our future-proof testing assets. The X Series is a progressive approach to signal analysis that spans instruments, measurements, and software. It gives you the flexibility to meet business and technical requirements now and in the future across multiple products and initiatives.
Product features:
Features:
9 kHz to 3.0 or 7.5 GHz; Internal preamplifier options up to 7.5 GHz
PowerSuite based on standard: Channel power, OBW, ACP, CCDF, SEM
Provides basic EMI pre-consistency measurement capabilities, including CISPR 16-1-1 bandwidth, detectors, amplitude correction factors, band presets, tuning and listening at marks, and limit lines
Performance:
± 0.5dB absolute amplitude accuracy
+13 dBm Third Order Intercept (TOI)
-145 dBm Display Average noise level (DANL)
-66 dBc W-CDMA ACLR Dynamic Range (Noise correction on)
