Product Description:
The Fluke ScopeMeter® 190-502 combine the highest safety ratings and rugged portability with the high performance of a bench oscilloscope. Designed for plant maintenance engineers and technicians, these tough ScopeMeter® test tools go into harsh, dirty, and hazardous industrial conditions to test everything from micro-electronics to power electronics applications.
The 190-502 ScopeMeter® is the one test tool you will reach for to tackle just about any troubleshooting task. They include a multimeter, TrendPlot™ and ScopeRecord™ roll paperless recorder modes and hands free operation with Connect-and-View™ triggering, and much more:
-
Two electrically isolated inputs
-
CAT III 1000 V / CAT IV 600 V safety rated
-
500 MHz bandwidth model
-
5 GS/s
-
Deep memory: 10,000 samples per channel waveform capture so you can zoom in on the details
-
Dedicated 5000 Count digital multimeter
-
Connect-and-View continuous auto-trigger, single shot, pulse width, and video triggering
-
ScopeRecord roll mode, capture waveform sample data for up to 48 hours
-
TrendPlot, trend measurement readings for up to 22 days
-
Advanced automatic measurements, power (Vpwm, VA, W, PF) and time (mAs, V/s, w/s)
-
IP-51 rated for dust and drip proof to withstand harsh environments
-
Isolated USB ports for memory devices and PC connectivity
-
Li-Ion battery for extended operating timespan
-
Up to 4 hours (BP290 included standard) or up to 8 hour with optional BP291
-
Charge spare battery using optional external battery charger EBC290
-
Easy-access battery door to make it easy to swap batteries
-
A handy slot to tether and lock down the oscilloscope while unattended using a standard Kensington® lock
